| Model Number |
MB500-KGNN-S00 |
| Exterior Color |
Black |
| Materials – Outlook |
Steel, Mesh, Plastic |
| Materials – Side Panel |
Tempered Glass |
| Dimensions (L x W x H) |
505 x 209 x 499mm (incl. Protrusions), 491 x 209 x 499mm (excl. Protrusions) |
| Volume |
51L |
| Motherboard Support |
Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature) |
| Expansion Slots |
7 |
| 5.25″ Drive Bays |
N/A |
| 2.5″ / 3.5″ Drive Bays (Combo) |
2 |
| 2.5″ Drive Bays |
4 |
| I/O Panel |
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button |
| ARGB Controller |
ARGB/PWM Hub |
| Pre-installed Fans – Top |
N/A |
| Pre-installed Fans – Front |
1x 120mm SickleFlow PWM ARGB |
| Pre-installed Fans – Rear |
1x 120mm MF120 non-LED Fan |
| Fan Support – Top |
3x 120mm, 2x 140mm |
| Fan Support – Front |
3x 120mm, 2x 140mm |
| Fan Support – Rear |
1x 120mm |
| Radiator Support – Top |
120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm) |
| Radiator Support – Front |
120mm, 140mm, 240mm, 280mm, 360mm |
| Radiator Support – Rear |
120mm |
| Clearance – CPU Cooler |
165mm/6.49″ |
| Clearance – PSU |
180mm/7.08″, (295mm / 11.61” with HDD cage removed) |
| Clearance – GFX |
410mm/16.1″ |
| Dust Filters |
Bottom, Front, Top |
| Power Supply Support |
ATX |
| Warranty |
2 years |
| Series |
MasterBox Series |
| Size |
Mid Tower |
