Radeon™ RX 9060 XT GAMING OC 16G
| Core Specifications | |
|---|---|
| Graphics Processing | Radeon™ RX 9060 XT |
| Core Clock | Boost Clock: up to 3320 MHz Game Clock: up to 2780 MHz |
| Stream Processors | 2048 |
| Memory | |
| Memory Clock | 20 Gbps |
| Memory Size | 16GB |
| Memory Type | GDDR6 |
| Memory Bus | 128-bit |
| Physical Attributes & Display | |
| Card Bus | PCI-E 5.0 |
| Digital Max Resolution | 7680 x 4320 |
| Multi-view Support | 3 |
| Dimensions (L x W x H) | 281 x 118 x 40 mm |
| PCB Form | ATX |
| Output | 2 x DisplayPort 2.1a 1 x HDMI 2.1b |
| Power & API Support | |
| Recommended PSU | 450W |
| Power Connectors | 1 x 8-pin |
| DirectX | 12 API |
| OpenGL | 4.6 |
| Note: *Boost Clock is the maximum frequency achievable on the GPU. Game Clock is the expected GPU clock when running typical gaming applications. | |
